Access door GX 21
200 x 100, with polyethylene seal, galv. steel
Article number
601GX
Access door GX 21 is available to buy in increments of 1
The MEZ-ACCESS DOOR GX 21 is ideally suited for areas with less space and its special crowning facilitates the positioning in the opening. The GX 21 has a temperature range from -70 to +70°C and the clearance between the upper edge of the knob or lever in closed position should be approx. 20 mm and the opening size is 200 x 100 mm. The two POM knobs allow a comfortable handling and operation of the access door.Technical Characteristics
Opening size: 200 x 100 mm
With PE gasket
Facilitates the positioning in the opening
Opening size: 200 x 100 mm
With PE gasket
Facilitates the positioning in the opening
| Part group | 160105 |
|---|---|
| Material | Galvanized steel |
