MEZ-CORNER-KLICK 30 - G27
Quick and secure corner joint for air duct profiles in the System 30
The MEZ-CORNER-KLICK 30 G27 is a two-part corner fitting for air duct profiles in the System 30. It enables a quick and reliable connection and supports efficient manufacturing and installation processes. You save time during installation and benefit from a sturdy corner joint. At the same time, the precision-fit design ensures a secure hold within the profile system.
The two-part corner brackets are easy to work with and create a reliable connection between air duct profiles. This reduces installation times and simplifies workflows. The galvanized steel construction provides reliable protection against corrosion and is suitable for professional use in ventilation and plant engineering.
Technical Highlights
- Two-part corner piece from Set 02
- Suitable for air duct profiles in System 30
- Manufactured from galv. steel
- Robust and reliable corner joint
- Precision-fit design for easy installation
- Secured against slipping out by a fold-over tab
Key Features
- Quick and straightforward installation
- High stability of the corner joint
- Secure connection of air duct profiles
- Corrosion-protected surface
- Suitable for manufacturing and installation
Additional features
- Reduced installation effort
- Reliable hold of the profile connection
- Durable design made from galvanized steel
- Precision-fit integration into existing profile systems
Installation
- Tap the fitting into the profile with a hammer
- Insert the flat section into the guide groove of the moulded part and tap it into the duct with a hammer
- Fold down the tab on the moulded part with a hammer until it rests against the flat section
- This reliably secures the corners against slipping out
Why is this MEZ-CORNER-KLICK 30 G27 right for you?
The MEZ-CORNER-KLICK 30 G27 is the ideal solution when air duct profiles need to be joined quickly, securely and permanently. The two-part design allows for easy installation whilst ensuring stable corner joints. This reduces installation times, optimises manufacturing processes and supports a reliable frame construction.
Application scenarios
- Manufacture of air ducts in System 30
- Framework constructions for ventilation ducts
- Ventilation and air-conditioning system installation
- Industrial and plant engineering
- Installation and maintenance of air duct systems
All information is provided without guarantee. Technical data, illustrations and prices are subject to change and are not binding. Errors excepted.
| Part group | 110702 |
|---|---|
| Material | Galvanized steel |
| Type | Two-part |
| Type variant | R27/G27 |
| Packaging unit | 1 St. |
