Access door RD 42
For rectangular air ducts, 400 x 200 mm
Article number
603
Access door RD 42 is available to buy in increments of 1
Opening size: 400 x 200 mm
With PE gasket
Heat stability -70°C to +70°C
MEZ-ACCESS DOOR RD 42 is an inspection opening for rectangular air ducts. The RD 42 is made of galvanised steel and has a gasket made of polyethylene. The two knobs, which consists of POM, allow a comfortable handling and operation of the access door and they have a maximum tensioning force from 1.200 to 1.700 Nm. The MEZ-ACCESS DOOR RD 42 is useable for a temperature range from -70 to +70°C. The opening size is 400 x 200 mm, the clearance between the duct wall and the upper edge of the knob or lever in closed position should be approx. 50 mm and the maximum pressure is 2.500 Pa.
With PE gasket
Heat stability -70°C to +70°C
MEZ-ACCESS DOOR RD 42 is an inspection opening for rectangular air ducts. The RD 42 is made of galvanised steel and has a gasket made of polyethylene. The two knobs, which consists of POM, allow a comfortable handling and operation of the access door and they have a maximum tensioning force from 1.200 to 1.700 Nm. The MEZ-ACCESS DOOR RD 42 is useable for a temperature range from -70 to +70°C. The opening size is 400 x 200 mm, the clearance between the duct wall and the upper edge of the knob or lever in closed position should be approx. 50 mm and the maximum pressure is 2.500 Pa.
| Teilegruppe | 160102 |
|---|---|
| Material | Stahl verzinkt |
| Verpackungseinheit | 1 St. |
