Access door RD 54 - SKK
Rectangular, with edge protection, 500 x 400 mm
Article number
606K
Access door RD 54 - SKK is available to buy in increments of 1
Opening size: 500 x 400 mm
With self-adhesive rubber edge molding
With PE gasket
The MEZ-ACCESS DOOR RD 54 SKK has a self-adhesive rubber edge molding which protects you from injuries at the assembly or disassembly and at the same time it serves as a gasket. The MEZ-ACCESS DOOR RD 54 SKK is made of galvanised steel, has a temperature resistance from -70 to +80°C and the clearance between the duct wall and the upper edge of the knob or lever in closed position should be approx. 67 mm. The two POM knobs allow a comfortable handling and operation of the MEZ-ACCESS DOOR RD 54 SKK. The gasket consists of polyethylene and the maximum pressure is 2.500 Pa.
With self-adhesive rubber edge molding
With PE gasket
The MEZ-ACCESS DOOR RD 54 SKK has a self-adhesive rubber edge molding which protects you from injuries at the assembly or disassembly and at the same time it serves as a gasket. The MEZ-ACCESS DOOR RD 54 SKK is made of galvanised steel, has a temperature resistance from -70 to +80°C and the clearance between the duct wall and the upper edge of the knob or lever in closed position should be approx. 67 mm. The two POM knobs allow a comfortable handling and operation of the MEZ-ACCESS DOOR RD 54 SKK. The gasket consists of polyethylene and the maximum pressure is 2.500 Pa.
| Teilegruppe | 160103 |
|---|---|
| Material | Stahl verzinkt |
