Access door RD 18 - V2A
rectangular air ducts, stainless steel, 180 x 80 mm
Article number
600E
Access door RD 18 - V2A is available to buy in increments of 1
Opening size: 180 x 80 mm
With PE gasket
Heat stability -70°C to +70°C
MEZ-ACCESS DOOR RD 18 is an inspection opening for rectangular air ducts. The RD 18 is made of stainless steel and has a gasket made of polyethylene. The two knobs, which consists of POM, allow a comfortable handling and operation of the access door and they have a maximum tensioning force from 1.000 to 1.500 Nm. The MEZ-ACCESS DOOR RD 18 is useable for a temperature range from -70 to +70°C. The opening size is 180 x 80 mm, the clearance between the duct wall and the upper edge of the knob or lever in closed position should be approx. 37 mm and the maximum pressure is 2.500 Pa.
With PE gasket
Heat stability -70°C to +70°C
MEZ-ACCESS DOOR RD 18 is an inspection opening for rectangular air ducts. The RD 18 is made of stainless steel and has a gasket made of polyethylene. The two knobs, which consists of POM, allow a comfortable handling and operation of the access door and they have a maximum tensioning force from 1.000 to 1.500 Nm. The MEZ-ACCESS DOOR RD 18 is useable for a temperature range from -70 to +70°C. The opening size is 180 x 80 mm, the clearance between the duct wall and the upper edge of the knob or lever in closed position should be approx. 37 mm and the maximum pressure is 2.500 Pa.
| Teilegruppe | 160102 |
|---|---|
| Material | Edelstahl V2A |
| Verpackungseinheit | 1 St. |
