MEZ-CORNER 30 - 104
Sturdy corner joint for System 30 – MEZ-CORNER 30 – Round hole, M10 – galv.
The MEZ-CORNER 30 – Round hole, M10 – galv. is a robust air duct profile connector for the SYPHON-FLANGE System 30 and has been developed for sturdy corner joints in large-diameter air ducts. The corner is designed for push-fit assembly and ensures a reliable, airtight connection thanks to the defined Sealing at the end face and inner flange.
In the production of air distribution systems, larger profile cross-sections often involve higher loads and stricter tightness requirements. Inaccurate connections here can quickly lead to rework or performance losses. This corner bracket supports a precise, stable connection and ensures reproducible results in the manufacturing process.
Technical Highlights
- Designed for the SYPHON-FLANGE System 30 for larger air ducts
- Side length of 104 mm for high stability in the corner area
- Round hole (Ø 11 mm) suitable for M10 screw connection
- Material thickness of 3.0 mm for durable and dimensionally stable connections
- Offset dimension of 30 mm for system-compliant integration
- Through-hole assembly with sealing at the end face and inner flange
Key features
- High stability for large-format air ducts
- Reliable sealing reduces leaks
- Clean and reproducible corner connections
- Reduced rework in production
- Durable thanks to galv. finish
Additional features
- Precisely fitting system component for System 30 applications
- Fewer readjustments due to stable connection
- Supports reliable and airtight airflow
Installation
- Simple push-through through the duct wall
- Quick and secure screw connection with M10
- Stable fit without time-consuming reworking
- Suitable for workshop and on-site assembly
Why is this corner right for you
The MEZ-CORNER 30 – Round Hole, M10 – galv. is the right choice for stable and airtight corner joints in the System 30. It ensures reliable results, particularly with larger air ducts, reduces assembly effort and supports efficient production processes.
Application scenarios
- Production of large-format air ducts
- Frame construction in the SYPHON-FLANGE System 30
- Ventilation and air conditioning system construction
- Industrial and plant engineering
- Maintenance and servicing of air duct systems
All information is provided without guarantee. Technical data, illustrations and prices are subject to change and are non-binding. Errors excepted.
| Part group | 110102 |
|---|---|
| Material | Galvanized steel |
| Screw hole | 11 mm |
| Clearance | 30 mm |
| Versioin | With round hole |
| Pallet | 7.500 St. |
| Packaging unit | 250 St. |
